QUAL-PEX ECO DUO

PRE-Insulated and Ducted Qual-PEX Plus+ ‘Easy-Lay’ Pipe for
Local & District Heating.

Qual-PEX Plus+ ‘Easy-Lay’ ECO Duo Pipe has been designed to
simplify and speed up installation by utilising standard Irish size
fittings and pipe and to greatly enhance energy conservation, thus
reducing energy costs.

• Irish size pipe eliminates the need for expensive adaptors.
• Use with standard compression fittings & Qual-PEX inserts.
• Manufactured in IRELAND.
• 50 year guarantee.
• Available in coils of 100m.
• Coils can be cut to order.
• Range of end caps available.
• Available in all leading Merchants. The Insulation:
The insulation of Qual-PEX Plus+ ‘Easy-Lay’ ECO Duo Pipe consists
of micro-cellular cross-linked polyethylene foam with a closed
Applications:
• Air/Water Heat Pumps. cellular structure, permitting low water vapour diffusion with good
• Geothermal Heat Pumps. insulation resistance to extreme temperatures. Moreover, Qual-
• Wood Pellet Boilers. PEX Plus+ ‘Easy-Lay’ ECO Duo Pipe maintains these high insulation
• Biomass & Biogas Boilers. properties over time. This is due to the superior characteristics of
• External Gas and Oil Boilers & many more. the cross linked PE foam, compared to other insulation materials
(e.g. PUR foam) which show a decline in their insulation capabilities
over time. Its unique moving layers design allows maximum
Product Description:
Two pre-insulated, Qual-PEX Plus+ ‘Easy-Lay’ Pipes encapsulated flexibility and very easy installation.
in 125mm of high performance insulation protected within a Installation:
corrugated PE-HD twin wall outer casing for maximum protection.
Delivering industry leading thermal insulation properties using There are no special tools or fittings required as both sizes of Qual-
Ireland’s leading plumbing and heating pipe. PEX pipes will fit with standard compression fittings that can be
bought in any Hardware outlet. Simply dig your trench, lay the pipe
in a serpentine pattern in the trench and back fill with sandy clay.
Allow 1% of the length of the pipe for expansion and contraction.
DESCRIPTION VALUE STANDARD Best practice would be to anchor the pipes at all fitting locations.

Density 28 kg/m3 ISO 845
Tensile Strength 270kPa ISO 1926
Water Absorption <1.0 % ISO 2896

Thermal Conductivity 0.036 W/mK EN 12677
Flammability B2 Normal DIN 4102
Recommended -50°C
Service t° up to +95°C

QUAL-PEX PLUS+ “EASY-LAY” ECO DUO
CODE DESCRIPTION SELLING UNIT PER METER
3095100590 Qual-PEX Plus+ EasyLay 1” Eco Duo 1
3095100591 Dust Caps 1

QUAL-PEX PLUS+ EASY-LAY PIPE 13
