QUAL-PLAST

PE PIPE

QUAL-PLAST LOW-DENSITY POLYTHENE PIPE
Manufactured to IS 134/1977.
PRODUCT CODE DESCRIPTION MEAN O.D. MEAN WALL PRESSURE PACK
THICKNESS RATING QTY
(MM) (MM) (BAR)
Normal Gauge
3096400000 1/2” x 150m NG 17.1 2.4 9 7
3096400010 3/4” x 150m NG 25.2 3.3 7.9 5
3096400020 1” x 150m NG 31.5 3.3 6.2 4
3096400030 1 1/4” x 150m NG 37.8 3.3 5.2 1
3096400040 1 1/2” x 150m NG 44.1 3.7 4.8 1
3096400050 2” x 150m NG 60.4 4.9 4.8 1
Heavy Gauge
3096400060 1/2” x 150m HG 20.9 4.6 14.5 5
3096400070 3/4” x 150m HG 27.2 4.6 10.3 4
3096400080 1” x 150m HG 34.1 4.6 8.3 1
MEDIUM DENSITY POLYETHYLENE PIPE MDPE PE80
Manufactured to EN12201
nom size OD 25m coil 50m coil 100m coil 150m coil
20mm 3 3 3 3
OUTSIDE DIAMETER (MM) 25mm 3 3 3 3
32mm 3 3 3 3
MIN MAX
40mm 3 3 3
20 20.3
50mm 3 3 3 3
25 25.3 63mm 3 3 3 3
32 32.3
Code Description Colour Size SDR Pack
50 50.4 Rating Qty
63 63.4 3096300000 20mm PE 80 PIPE (PN 16 BAR) BLUE 25m SDR9 10
3096300040 25mm PE 80 PIPE (PN 12.5 BAR) BLUE 25m SDR11 8
3096300080 32mm PE 80 PIPE (PN 12.5 BAR) BLUE 25m SDR11 7
3096300150 50mm PE 80 PIPE (PN 12.5 BAR) BLUE 25m SDR11 1
3096300190 63mm PE 80 PIPE (PN 12.5 BAR) BLUE 25m SDR11 1

3096300010 20mm PE 80 PIPE (PN 16 BAR) BLUE 50m SDR9 8
3096300050 25mm PE 80 PIPE (PN 12.5 BAR) BLUE 50m SDR11 7
3096300090 32mm PE 80 PIPE (PN 12.5 BAR) BLUE 50m SDR11 6
3096300145 40mm PE 80 PIPE (PN 12.5 BAR) BLUE 50m SDR11 1
3096300160 50mm PE 80 PIPE (PN 12.5 BAR) BLUE 50m SDR11 1
3096300200 63mm PE 80 PIPE (PN 12.5 BAR) BLUE 50m SDR11 1

3096300020 20mm PE 80 PIPE (PN 16 BAR) BLUE 100m SDR9 7
3096300060 25mm PE 80 PIPE (PN 12.5 BAR) BLUE 100m SDR11 5
3096300100 32mm PE 80 PIPE (PN 12.5 BAR) BLUE 100m SDR11 4
3096300130 40mm PE 80 PIPE (PN 12.5 BAR) BLUE 100m SDR11 1
Manufactured and certified to EN12201 3096300170 50mm PE 80 PIPE (PN 12.5 BAR) BLUE 100m SDR11 1
specification. Blue Medium Density (PE80) 3096300210 63mm PE 80 PIPE (PN 12.5 BAR) BLUE 100m SDR11 1
Polyethylene Service Pipes for Potable
Water and Industrial uses manufactured 3096300030 20mm PE 80 PIPE (PN 16 BAR) BLUE 150m SDR9 6
in accordance to EN12201 Specification. 3096300070 25mm PE 80 PIPE (PN 12.5 BAR) BLUE 150m SDR11 5
Also manufactured to BSEN12201 with BS 3096300110 32mm PE 80 PIPE (PN 12.5 BAR) BLUE 150m SDR11 4
Kitemark.
3096300140 40mm PE 80 PIPE (PN 12.5 BAR) BLUE 150m SDR11 1
Max operating temperatures - 16 bar for 3096300180 50mm PE 80 PIPE (PN 12.5 BAR) BLUE 150m SDR11 1
20mm and 12.5 bar for all other sizes. 3096300220 63mm PE 80 PIPE (PN 12.5 BAR) BLUE 150m SDR11 1
